ST-CA1200 Conductive Adhesive
Introduction
Use
Parameters
|
Model |
ST-CA1200 |
|
Hardness (Shore A) |
60±5 |
|
Tensile Strength (MPa) |
≥2.0 |
|
Shear Strength (MPa) |
≥2.0 |
|
Elongation At Break (%) |
≥50 |
|
Thermal Conductivity (W / m · K) |
1.00 |
|
Dielectric Strength (kV / mm) |
≥15 |
|
Volume Resistivity (Ω · cm) |
1.0x1012 |
|
Flame-Retardant Grade (UL 94) |
V-0 |
Construction Recommendations
1. Clean: Clean the dust, water, and oil pollution on the surface of the product, and keep the surface dry.
2. Stirring: Before the ratio, stir the agent first to divide the pigment (filler) sunk at the bottom into the glue liquid.
3. Ratio: Weigh the product separately according to the a / b ratio of the purchased product and pour it in turn (* Note: according to the weight ratio, non-volume ratio).
4. Mixing: Mix the mix of a / b glue, and fully stir to avoid incomplete curing.
5. Defoaming: The mixed glue static 5-10 bubbles will automatically discharge if conditions can be vacuum defoaming.
6. Use glue: Pour the glue into the adhesive products, please use it up within the operational time.
