ST-CF1500 Polyurea / Polyurethane Coated Adhesive
Introduction
Use
Parameters
|
Model |
ST-CF1500 |
|
Density (g/cm3) |
1.0±0.1 |
|
Viscosity (MPa·s) |
100-150 |
|
Water Absorption (%) |
0.01 |
|
Dielectric Strength (KV / Mm) |
19.0 |
|
Dielectric Constant (@ 1 MHz) |
3.0-3.5 |
|
Dielectric Loss Factor (@ 1 MHz) |
0.035 |
|
Volume Resistivity (Ω · cm) |
3.5x1014 |
|
Adhesion (Grid Test) |
Level 1 |
|
Solid Content |
52±3% |
|
Double 85 Test |
Pass |
Construction Recommendations
1. Clean: Clean the dust, water, oil pollution on the surface of the product, and keep the surface dry.
2. Stirring: Before the ratio, stir the A agent first to divide the pigment (filler) at the bottom into the glue liquid.
3. Mix ratio: Weigh the product separately according to the A / B ratio of the purchased product and pour it in turn (* Note: according to the weight ratio, non-volume ratio).
4. Mixing: Mix the mix of A / B glue, fully stir to avoid incomplete curing.
5. Defoaming: The mixed glue static 5-10 bubbles will automatically discharge if conditions can be vacuum defoaming.
6. Use glue: Pour the glue into the adhesive products, please use it up within the operational time.
