ST-PE1700 Polyurea / Polyurethane High Strength Elastic Sealing Glue
Introduction
Use
Parameters
|
Model |
ST- PE 1700 |
|
Viscosity (MPa·s) |
A:1000-2000 B:3500-5000 |
|
Volume Ratio |
1:2 |
|
Post-Mixing Density (g / cm3) |
2.4±0.1 |
|
Thermal Conductivity (W/ m · K) |
1.5 |
|
Tensile Strength (MPa) |
8.0 |
|
Elongation At Break (%) |
30% |
|
Hardness (Shore A) |
70 |
|
Dielectric Strength (kV / mm) |
≤17 |
|
Volume Resistivity Of (Ω•㎝) |
≥ 1.5*1013 |
|
Salt Fog Test |
Pass |
|
Double 85 Test |
- |
|
Flame-Retardant (UL 94) |
V0 |
|
Hot And Cold Shock (100 Cycles) |
- |
|
Working Temperature (℃) |
-30~80 |
|
Operation Time (Min) |
40 |
Construction Recommendations
1. Clean: Clean the surface dust, water, and oil of the product, and keep the surface dry.
2, stirring: Before the ratio, stir the A agent first to divide the pigment (filler) at the bottom into the glue.
3. Ratio: Weigh the product separately according to the A / B ratio of the purchased product and pour it in turn (* Note: according to the weight ratio, non-volume ratio).
4. Mix: Mix the A / B glue, and fully stir to avoid incomplete curing.
5. Defoaming: Leave the mixed glue into 5-10 bubbles will automatically discharge. If possible, vacuum defoaming can be defoamed.
6. Seal: Seal the defoaming adhesive material into the adhesive products, please use it up within the operational time.
